GY-271 QMC5883L 3-Axis Electronic Compass Module – Magnetic Field Sensor for Arduino, Raspberry Pi & Robotics Projects
GY-271 QMC5883L 3-Axis Electronic Compass Module – Magnetic Field Sensor for Arduino, Raspberry Pi & Robotics Projects
The GY-271 QMC5883L Electronic Compass Module is a compact and highly sensitive 3-axis magnetic field sensor that allows your project to detect direction and orientation with precision. Ideal for Arduino, Raspberry Pi, flight controllers, drones, and robotics, this module provides reliable heading data by sensing Earth’s magnetic field.
Equipped with the QMC5883L chip, it offers improved accuracy and lower noise than its predecessor (HMC5883L), making it suitable for GPS navigation, attitude heading reference systems (AHRS), and electronic compasses.
🔧 Key Specifications:
Chipset: QMC5883L
Axes: 3-axis magnetometer (X, Y, Z)
Interface: I2C (up to 400kHz)
Operating Voltage: 3.3V – 5V
Measurement Range: ±2 to ±8 Gauss
Resolution: 12-bit ADC output
Board Size: Approx. 13mm × 18mm
Mounting Holes: Included for secure installation
Pinout: VCC, GND, SDA, SCL
Customize PCB
Customize PCB
Need help building your PCB Message us on Facebook!
📩 INQUIRE with us on Messenger
How to Request a PCB Layout/Design:
- Send your complete schematic or diagram via our Facebook page.
- We will assess your diagram and provide a quotation based on the complexity and requirements.
PCB Layout & Design Rules:
- All diagrams must be clear and properly labeled.
- Specify the desired board size, number of layers, and component types if applicable.
- Rush requests may incur additional charges.
- We do not accept hand-drawn or incomplete schematics.
- Files will be delivered in Gerber and/or PDF format as requested.
