PCB Layout & Design Services

We provide professional PCB layout and design services for electronics projects, prototypes, and small to medium production needs. Our goal is to deliver accurate, manufacturable, and well-documented PCB designs tailored to your specific requirements.

How to Request a PCB Layout/Design:

• Send your complete schematic or diagram via our Facebook page.
• We will assess your diagram and provide a quotation based on the complexity and requirements.

Special Offer for New Customers!!

New customers receive a special introductory discount on their first PCB layout/design project.
This allows us to review your design requirements and build a long-term working relationship.

How to Request a PCB Layout / Design

1. Send your complete schematic or diagram via our Facebook page.
2. Our team will review your diagram carefully to understand the design scope and requirements.
3. A detailed quotation will be provided based on:

• • Design complexity
  • Board size and number of layers
  • Components and package types
  • Special routing or manufacturing requirements

📌 Providing your diagram is essential so we can give you an accurate and fair quotation.

PCB Layout & Design Requirements

To ensure quality and accuracy, please note the following:

• All schematics must be clear, complete, and properly labeled
• Specify:
  • Board dimensions (if available)
  • Number of PCB layers
  • Preferred components or footprints (if any)
• Hand-drawn, unclear, or incomplete schematics are not accepted
• Rush or urgent requests may incur additional charges

What’s Included in the Design Package

Each completed project includes the following deliverables:

✅ 2D PCB layout images
✅ 3D PCB render images
✅ PCB Gerber files (ready for fabrication)
✅ Bill of Materials (BOM)
✅ Component Placement List (CPL / Pick-and-Place file)
✅ Wiring diagram (PDF)
✅ PCB board layout (PDF)

All files are prepared to be manufacturer-ready and easy to review.

Pricing Information

Pricing is project-based and depends on:

• The submitted schematic or diagram
• Board size and layer count
• Types of components used (SMD, through-hole, fine-pitch, BGA, etc.)
• Design complexity and routing difficulty

📌 Final pricing is confirmed only after reviewing the client’s diagram.

Design Review & Approval Process

Before final delivery:

• The client will receive preview files for checking
• Please review carefully for:
  • Errors
  • Missing information
  • Clarifications or revisions
• Once the design is confirmed and approved, the final files will be sent to the client’s email

⚠️ After final approval, any major changes may be treated as a new request.

Payment Methods

Philippines (Local Clients):

• GCash
• Bank Transfer

International Clients:

• PayPal

📌 Design work starts after payment confirmation unless otherwise agreed.
