This download provides a complete design package for the TP4056 Charging Module with USB Type-C input, including the KiCad symbol, PCB footprint, and 3D STEP model. This module is widely used for lithium-ion and lithium-polymer battery charging applications and is perfect for DIY electronics, wearable devices, and low-power embedded systems.
The KiCad symbol and footprint are cleanly designed for easy integration into your schematic and PCB layout. The included STEP file allows for precise 3D placement and enclosure fitting in software such as Fusion 360, SolidWorks, and Altium. This package saves you time by eliminating the need to manually model or design from scratch.
Designed for engineers, makers, and product developers, this ready-to-use library element ensures accuracy and consistency in both electrical and mechanical aspects of your project.
